The Cutter Suction Dredger 500 (20 inch) is a detachable dredger equipped with a built-in dredge pump and drive system. This enhances the efficiency and compactness of the dredger, making it easy to transport and allowing for high production rates.
We provide various customization choices to suit the CSD 500 for any project.
The SCO HID 20-inch cutter suction dredger has a total power installation of 1500kw, featuring a Cummins main engine and auxiliary engine. The pump can discharge a flow capacity of 3500-4000m3/h. It can dredge up to a maximum depth of 14m underwater and has a discharge distance capability of 1500m.
The CSD 500 has a shallow draft of 1.4m, thanks to its three pontoon design consisting of one central pontoon and two side pontoons. These pontoons provide buoyancy, enabling the dredger to easily operate in both inshore and offshore waters.
This dredger can be disassembled into one central pontoon, two side pontoons, a control cabin, spuds, and the cutter ladder. The dis-mountable design of the CSD 500 makes it practical for transportation and storage.
We offer a wide range of customization options for the CSD 500 cutter suction dredger, including hydraulic propulsion, spud carrier, anchor booms, automated systems, and production meters.If you have other requirements, do not hesitate to ask.
It is a remarkable dredging equipment for channel dredging, port maintenance and land reclamation.
